3.2-
DENOMINA
TION
OF
THE
COMPONENTS
AND
DIMENSIONS
LEGEND:
1)
Power supply cable
2)
Support heads
3)
Support
4)
Opening stroke adjustment on both sides
5)
Actuator
6)
Chain pin
7)
Bracket for bottom hung opening
8)
Window frame connection bracket
1
4
5
3
2
6
8
7
Dimensions in mm
8
ACK4
3- TECHNICAL DESCRIPTION
INST
ALLA
TION
AND USE ISTRUCTIONS
VER.0.0
REV
.1
1.12
Fig. 2
7
9
