3.8.2.3 DC Current Measuring
WARNING!
Shut down the power of the test circuit; connect the meter with the circuit for
measurement.
a. Connect the black test lead to the COM jack and the red test lead to the mA
jack for a maximum of 660mA current. For a maximum of 10A, move the red
lead to the 10A jack.
b. Press LEFT / RIGHT to set the highlight cursor on the DC current
measurement.
c. Connect test leads in series with the load under measurement.
d. The value will be displayed on the LCD. The polarity of the red lead connection
will be indicated along with the voltage value.
