3.8.2.7 Diode Testing
a. Connect the black test lead to the COM jack and the red test lead to the
jack.
b. Press LEFT / RIGHT to set the highlight cursor on the Diode test.
c. Connect test leads across to the anode, the black lead to the cathode of the
diode under testing.
d. The value will be displayed on the LCD.
