TOPVERT P1 Series : 3-Phase ，
，，
，200/-15% ~ 240/+10%Vac, 47 ~ 63Hz /[400Hz]
Model
Applicable Motor
(230V 4 P )
Rated Output Source Enclosure structure
TOPVERT
P1-xxxxx
Power
(kW)
Horse
Power
(Hp)
Capacity
(kVA)
Current
(A)
Voltage
(V)
Frequency
(Hz)
Current
(Amax.)
Cooling
Method
(Noise
level)
Degree of
protection
Net
Weight
(kg)
Frame
Code
230P7 0.75 1 1.4 3.6
3- Phase
，
0-100% of supply voltage
0 ~ 600
4
Fan-
cooled
(<70
dB/1M)
IP 20
NEMA 1
[IP 21
/40/42/
50/52
Optional]
2.6
P1-A
231P5 1.5 2 2.4 6 6.6 2.8
232P2 2.2 3 3.6 9 9.9 2.8
233P7 3.7 5 5.3 13.2 15 2.8
235P5 5.5 7.5 8.1 20.4 22 3.0
237P5 7.5 10 12 30 33 3.2
23011 11 15 16 39.6 44 4.0 P1-B
23015 15 20 23 58.8 65 11.9
P1-C
23018 18.5 25 31 75 86 12.3
23022 22 30 36 90 99 13.0
23030 30 40 43 108 119 13.5
23037 37 50 57 144 158
IP 00
NEMA 0
[IP 20/21
/40/42/
50/52
NEMA 1
Optional]
32.7
P1-D
23045 45 60 69 174 191 33.8
23055 55 75 87 218.4 240 34.6
23075 75 100 111 278.4 306 58.0
P1-F
23090 90 125 143 360 396 59.4
23110 110 150 172 432 475
Fan-
cooled
(<80
dB/1M)
192
P1-G
23132 132 175 210 520 581 192
[ ]: Optional
