PLACING THE TOOL IN SERVICE
1. Ensure the reaction arm is properly attached and secured to the splined section of the torque tool.
2. Select your desired square drive size and bolt/nut AF size impact socket or hex-drive socket for use.
3. Secure impact socket onto the tool square drive with a safety pin and secure a safety o-ring on the
socket.
4. See illustration below for details:
1.
1.
1.
2.
2.
2.
3.
Slide Rubber Safety Ring
Over Safety Pin
Safety Pin
Safety Screw
PLACING THE TOOL IN SERVICE
To Next Page
