ASSEMBLY DIAGRAM
REF# PART # DESCRIPTION QTY
1 TR6201E.2 Seat assembly 1
2 TR6375E.1.1(ASM) Seat base with lever 1
3 GB97.1-6 Washer M6 4
4 GB93-6 Spring washer M6 4
5 GB818-M6X20 Screw M6x20 4
6 TR6188C.6 Pneumatic pump 1
7 TR6378.1 Metal tool tray 1
8 TR6206-6 Plastic end cap 5
9 TR6378.1 Metal frame base 1
10 TR6208.1 Caster assembly M6 5
Safe Operating Temperature is between 40°F – 105°F (4°C - 41°C)
