Tornado VS4

– 8
Technical specifications
Electrical connection
Mains voltage V 120
Frequency Hz 1~ 60
Voltage in the steam gun V 24
Type of protection -- IPX4
Protective class -- I
Performance data
Rated power W 1500
Rated current, Pump A 0.3
Max. operating pressure psi (MPa) 58 (0.4)
Permitted operating pressure psi (MPa) 87 (0.6)
Max. work temperature °F (°C) 293 (145)
Heating time per litre of water min ca. 5.5
Steam quantity (max.) oz/min (g/min) 2.6 (75)
Dimensions and weights
Typical operating weight lbs (kg) 17.6 (8.0)
Max. water capacity gal (l) 1.1 (4.0)
Tank content gal (l) 0.5 (2.0)
Boiler capacity gal (l) 0.6 (2.4)
Length x width x height in (mm) 18.5 x 12.5 x 11.0
(475 x 320 x 275)
Power cord SJTW 3/14 AWG
Part no.: Cable length
Tornado 6.647-791.0 13 ft (4 m)
