Setup
Note: Determine the left and right sides of the machine
from the normal operating position.
Loose Parts
Note: Use the chart below to verify all parts have been shipped.
DESCRIPTION QTY. USE
Shift lever
Shift lever mounting bracket
Washer, 1/4 in.
Bolt, 1/4 x 2 in.
1
1
1
1
Installing the shift lever
Fuel tank
Control panel
Bolt, 5/16 x 7/8 in.
Lock washer, 5/16 in.
Washer, 5/16 in.
Hose clamp
1
1
4
4
4
2
Installing the control panel and fuel tank
Upper handle
Flanged bolt, 3/8 x 1 in.
Flange nut, 3/8 in.
1
4
4
Installing the upper handle
Screw self-tapping
Star washer
Wire tie
1
1
1
Installing the wire harness
Rod fitting
Clevis pin
Washer, 1/4 in.
Hairpin cotter
2
2
2
2
Installing the control rods
Operator’s Manual
Engine Operator’s Manual
Parts Catalog
Registration card
1
1
1
1
Read before operating machine
Fill out and return to Toro
Installing the Shift Lever
1. Align mounting block with flats of shaft on top of
transmission and slide onto shaft (Fig. 2).
Note: Do not remove rubber washer on transmission shaft.
2. Align mounting hole in lever with mounting block on
transmission. Secure lever to transmission with 2 in.
(51 mm) bolt and washer. Torque bolt to 115 in.–lb.
(13 N.m).
