Important The grass deflector must be able to lower
down into position. Lift the deflector up to test that it
lowers into the full down position.
6
1
5
m–5037
4
2
3
7
8
Figure 68
1. Bolt
2. Spacer
3. Locknut
4. Spring
5. Spring installed
6. Grass deflector
7. Place behind deck edge
before installing bolt
8. Hook end of spring
