MowerBeltMaintenance
InspectingtheBelts
ServiceInterval:Every25hours—Checkthebeltsforwear
orcracks.
Checkthebeltsforcracks,frayededges,burnmarks,orany
otherdamage.Replacedamagedbelts.
ReplacingtheMowerBelt
Thesignsofawornbeltincludesquealingwhilethebeltis
rotating,bladesslippingwhilecuttinggrass,andfrayededges,
burnmarks,andcracksonthebelt.Replacethemowerbeltif
anyoftheseconditionsareevident.
1.Parkthemachineonalevelsurfaceanddisengagethe
blade-controlswitch.
2.Movethemotion-controlleversoutwardtothePARK
position,shutofftheengine,removethekey,and
waitforallmovingpartstostopbeforeleavingthe
operatingposition.
3.Settheheight-of-cutatthelowestcuttingpositionof
38mm(1-1/2inches).
4.Removethepulleycovers(Figure70).
g188324
Figure70
1.Cover2.Screw
5.Usingaspring-removaltool(ToroPartNo.92-5771),
removetheidlerspringfromthedeckhooktoremove
tensionontheidlerpulley,androllthebeltoffthe
pulleys(Figure71).
WARNING
Thespringisundertensionwheninstalled
andcancausepersonalinjury.
Becarefulwhenremovingthebelt.
g017639
1
2
3
3
5
4
6
7
7
g017639
Figure71
MowerDeckswith2Blades
1.Idlerpulley5.Enginepulley
2.Mowerbelt
6.Spring-removaltool
3.Outsidepulley
7.Mower-deckhandles
4.Spring
