Toro ProStripe 560 Installation Instructions

Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure Description
Qty .
Use
1
No parts required
–
Prepare the machine.
Brush-adjustment bracket 1
Groomer brush
1
Capscrew (8 x 60 mm)
4
W asher (8 mm)
8
Locknut (8 mm)
4
Brush-height plate 2
Carriage bolt (8 x 25 mm)
2
Knob 2
Strut (brush)
2
Capscrew (6 x 20 mm)
2
W asher (6 mm)
4
2
Locknut (6 mm)
2
Assemble the brush mount.
Lower brush bracket 2
Self-tapping, ange-head screw (6 x 20
mm)
4
Capscrew (6 x 20 mm)
2
W asher (6 mm)
4
3
Locknut (6 mm)
2
Assemble the brush kit to the machine.
Capscrew (6 x 20 mm)
2
W asher (6 mm)
4
4
Locknut (6 mm)
2
Assemble the brush struts to the
machine.
5
Front ns
1
Install the front ns and the wheels.
6
No parts required
–
Finish the kit installation.
1
Preparing the Machine
No Parts Required
Procedure
W ARNING
The blade is sharp; contacting the blade can
result in serious personal injury .
W ear gloves when servicing the blade.
W ARNING
T ipping the machine may cause the fuel to
leak. Fuel is ammable and explosive, and
can cause personal injury .
Run the engine dry or remove the fuel with a
hand pump; never siphon the fuel.
Important: Do not add fuel to the fuel tank prior
to installing the brush kit.
For the ProStripe 560 mower:
1. Run the engine to empty the fuel tank or remove
the fuel with a hand pump.
If you do not use all the fuel in the tank, use a
hand fuel pump to remove the fuel.
2
