Toro Recycler 20333 - Setup; Installing the Blade-Control Bar; Assembling and Unfolding the Handle

132-4470
TractionAdjustment
1.Attention;readthe
Operator'sManual—1)
Loosentheknobbyturning
itcounterclockwise;2)Pull
thecable(s)awayfrom
theenginetodecrease
thetraction,orpushthe
cable(s)towardtheengine
toincreasethetraction;
3)Tightentheknobby
turningitclockwise.
2.ScantheQRcodefor
moreinformationon
tractionadjustment.
Setup
Important:Removeanddiscardtheprotectiveplastic
sheetthatcoverstheengineandanyotherplasticor
wrappingonthemachine.
1
InstallingtheBlade-Control
Bar
NoPartsRequired
Procedure
Installtheblade-controlbarintotheupperhandle(Figure3).
Figure3
2
AssemblingandUnfoldingthe
Handle
NoPartsRequired
Procedure
1.Removeandsavethe2handleknobsand2carriage
boltsfromthehandlebrackets(Figure4).
