Toro Recycler 20334 User Manual

Note:Yourbatterychargermayhavea2-colorLED
displaythatindicatesthefollowingstatesofcharging:
•Aredlightindicatesthatthechargerischarging
thebattery.
•Agreenlightindicatesthatthechargerisfully
chargedorthechargerisdisconnectedfromthe
battery.
•Aashinglightthatalternatesbetweenredand
greenindicatesthatthebatteryisnearlyfully
charged.Thisstatelastsonlyafewminutesuntil
thebatteryisfullycharged.
ReplacingtheFuse
ForElectric-StartModels
Ifthebatterydoesnotchargeortheenginedoesnot
runwiththeelectricstarter,thefusemaybeblown.
Replaceitwitha40Aplug-intypefuse.
1.Raisethereardeectorandlocatethebattery
compartment(Figure30).
g009506
Figure30
1.Reardeector
3.Battery
2.Screw
4.Batterycompartment
2.Wipeawayanydebrisfromthebattery
compartmentarea.
3.Removethescrewthatsecuresthebattery
compartment,pulloutthebattery,andlocatethe
fuse(Figure31).
g030022
Figure31
1.Cover
3.Fuse
2.Fuseholder
4.Replacethefuseinthefuseholder(Figure31).
Note:Yourmachinecomeswithasparefusein
thebatterycompartment.
5.Installthebatterycompartmentwiththescrew
thatyouremovedinstep3.
6.Installthecoveroverthebatterycompartment.
7.Lowerthereardeector.
25

Toro Recycler 20334 Specifications

General

Mulching Capability	Yes
Rear Wheel Size	10 inches
Starter	Recoil
Deck Material	Steel
Bagging Capability	Yes
Side Discharge Capability	Yes
Cutting Width	22 inches
Drive System	Rear-Wheel Drive
Cutting Height	1.0 - 4.0 inches
Fuel Capacity	1.0 qt (0.95 L)
Drive Type	Rear Wheel Drive
Wheel Size	10 inches (rear), 7 inches (front)
Oil Capacity	20 oz
Engine	Briggs & Stratton 675EX Series
