Toro Recycler 20339 - Lawn Mower Setup and Initial Assembly; Unfolding the Mower Handle

131–4514
1.Warning—readtheOperator'sManual.
2.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts;keepallguardsand
shieldsinplace.
3.Cutting/dismembermenthazardofhandorfoot,mower
blade—disconnectthespark-plugwireandreadthe
instructionsbeforeservicingorperformingmaintenance.
4.Thrownobjecthazard—keepbystandersasafedistance
fromthemachine;stoptheenginebeforeleavingthe
operatingposition;pickupanydebrisbeforemowing.
5.Cutting/dismembermenthazardofhandorfoot,mower
blade—donotoperateupanddownslopes;operatesideto
sideonslopes;lookbehindyouwhenbackingup.
Setup
Important:Removeanddiscardtheprotectiveplastic
sheetthatcoverstheengine.
1
UnfoldingtheHandle
NoPartsRequired
Procedure
WARNING
Unfoldingthehandleimproperlycandamagethe
cables,causinganunsafeoperatingcondition.
•Donotdamagethecable(s)whenfoldingor
unfoldingthehandle.
•Ensurethatthecable(s)areroutedtotheoutside
ofthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Movethehandlerearwardtotheoperatingposition
(Figure3).
Figure3
2.Setthehandlelock(Figure4)untilthepinclicksin
placetolockthehandleintotheoperatingposition.
5
