Toshiba 32AF41 - Chassis and Cabinet Replacement Parts List

– 22 –
SPECIFIC INFORMATIONS
Location
No.
Part No. Description
CAPACITORS
C102 24793221 CAPACITOR, ELECTROLYTIC CE04G 10V 220UF M
C105 24212102 CAPACITOR, CERAMIC DISK CK45 B 50V 1000PF K
C106 24797479 CAPACITOR, ELECTROLYTIC CE04G 50V 4.7UF M
C107 24763221 CAPACITOR, ELECTROLYTIC, 16V 220UF M
C110 24794470 CAPACITOR, ELECTORLYTIC CE04G 16V 47UF M
C201 24503041 CAPACITOR, MT PLA CAP 63V 0.1UF J
C204 24797010 CAPACITOR, ELECTROLYTIC CE04G 50V 1.0UF M
C205 24794100 CAPACITOR, ELECTROLYTIC CE04G 16V 10UF M
C207 24436270 CAPASITOR, CERAMIC DISC CC45SL 50V 27PFJ
C208 24436270 CAPASITOR, CERAMIC DISC CC45SL 50V 27PFJ
C209 24436270 CAPASITOR, CERAMIC DISC CC45SL 50V 27PFJ
C213 24503041 CAPACITOR, MT PLA CAP 63V 0.1UF J
C216 24797100 CAPACITOR, ELECTROLYTIC CE04G 50V 10UF M
C220 24539474 CAPACITOR, MT PLA CAP M 50V 474J MUL
C220 24797229 CAPACITOR, ELECTROLYTIC CE04G 50V 2.2UF M
C224 24503041 CAPACITOR, MT PLA CAP 63V 0.1UF J
C225 24503041 CAPACITOR, MT PLA CAP 63V 0.1UF J
C226 24503041 CAPACITOR, MT PLA CAP 63V 0.1UF J
C245 24206108 CAPACITOR, ELECTROLYTIC CE04WS 50V 0.1UF M 7L 3A
C261 24503041 CAPACITOR, MT PLA CAP 63V 0.1UF J
C262 24503041 CAPACITOR, MT PLA CAP 63V 0.1UF J
C263 24503041 CAPACITOR, MT PLA CAP 63V 0.1UF J
C300 24503041 CAPACITOR, MT PLA CAP 63V 0.1UF J
C304 24693473 CAPACITOR, PLASTIC FILM CQ921 M 100V 0.047MF J
C306 24073059 CAPACITOR, ELECTROLYTIC CE04P 25V 3300UF M 3A
C308 24797221 CAPACITOR, ELECTROLYTIC CE04G 50V 220UF M
C310 24073094 CAPACITOR, ELECTROLYTIC CE04P 50V 1000UF M 3A
C312 24503037 CAPACITOR, MT PLA CAP 63V 0.047UF J
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY
PRECAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols “ ” in the schematic diagram and the parts list designate com-
ponents which have special characteristics important for safety and should be replaced only with types identical to
those in the original circuit or specified in the parts list. The mounting position of replacements is to be identical with
originals. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not
degrade the safety of the receiver through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model
number and Description.
• The PC board assembly with
*
mark is no longer available after the end of the production.
Model : 32AF41
Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
CHASSIS AND CABINET REPLACEMENT PARTS LIST
