– 48 –
SPECIFIC INFORMATIONS
Location
No.
Part No.
Description
SR81 23146564 RELAY, DC12V, TV5, DG-3
SR83 23146564 RELAY, DC12V, TV5, DG-3
V901A 23903145 SOCKET, WFOCUS ISD35SE INCHANG ISD-35S-E
W661 23351088 SPEAKER, SPK1360, 60X120 8-OHM 5W
W662 23351088 SPEAKER, SPK1360, 60X120 8-OHM 5W
X401 23153721 CERAMIC RESONATOR, 503KHZ
X501 23153961 CRYSTAL, 3.58MHZ
XA01 23153504 CERAMIC RESONATOR, 8.00MHZ 25OHM
XA01 23153504 CERAMIC RESONATOR, 8.00MHZ 25OHM
Z401 23140203 SPARK GAP, 2.0-3.0KV C-010 AG20PC152F-L3N
PC BOARD ASSEMBLIES
*
U801 23708391 PC BOARD ASSY, PCB PWR/D0154B PD0154B
*
U901 23708395 PC BOARD ASSY, CRT/D PB9973A
*
U901 23708502 PC BOARD ASSY, PCB CRT/D9973B PB9973B
*
U902 23708410 PC BOARD ASSY, SIGNALPD0155 PD0155A 32AF4
*
U905 23786166 PC BOARD ASSY, PW UNIT 3LINE B PB9398A
*
UA01 23786539 PC BOARD ASSY, PCB CNT1 PD0150B
*
UA02 23786540 PC BOARD ASSY, PCB CNT2 PD151 32AF41
PICTURE TUBE
V901 23312930 PICTURE TUBE, ITC32VRF LH0.97 A80ERF031X13
TUNER
H001 23321410 TUNER, TIF 181CH IIC PH SAIKO EL969L
ACCESSORIES
K912 23306359 REMOCON HAND UNIT IR, CTVUSA CT-90037
Y101 23565273 OWNER’S MANUAL, (ENG.32AF41) 32AF41
Y101F 23565274 OWNER’S MANUAL, (FRE.32AF41) 32AF41
CABINET PARTS
A201 23540658 COVER, FRONT COVER ASSY 32AF41 32AF41
A213 23427976 DOOR, DOOR 32AF41
A214 23451976 PUSH CATCH, CLICK
A411 23540031 COVER, BACK COVER PROPER 32AFX60
A701 23064255 CARTON, CARTON 32AF60
A703 23946056 PACKING, TOP PACKING 32AFX60 32AFX60
A708 23946057 PACKING, BOTTOM PACKING 32AFX60 32AFX60
