Toshiba 50L4300 Series User Manual

31
Using the TV’s features
Pin No. Signal name Pin No. Signal name
1R 9NC
2 G 10 Ground
3 B 11 NC
4
NC (not
connected)
12
DDC Data
5 Ground 13 H-sync
6 Ground 14 V-sync
7 Ground 15 DDC Clock
8 Ground
Using the PC Settings
• First press o until the video input mode list
appears on the screen, then press  or  and
OK in order to select the PC input mode (- page
24).
• This function may not be available for some signal
or if no signal is received.
• The optimum points of the Clock Phase
and Sampling Clock adjustments may be
incomprehensible according to the input signals.
Adjusting the picture position
1 From the Display Settings in the PREFERENCES
menu, press  or  to select PC Settings.
2 Press OK to display the PC Settings menu.
PC Settings
Horizontal Position
Vertical Position
Clock Phase
Sampling Clock
Reset
0
0
0
0
3 Press  or  to select an option you want to
adjust. Press  or  to adjust the settings as
required.
Adjusting the Clock Phase of the picture
If the Clock Phase, which synchronize the PC signal
and LCD display, is not optimized, the picture will
blur.
This function enables you to adjust Clock Phase
and display a clear picture.
1 From the PC Settings menu, press  or  to
select Clock Phase.
2 Press  or  to obtain a clear picture.
Adjusting the Sampling Clock
If the Sampling Clock does not match with the dot
clock frequency of the PC, blurred picture detail will
occur, or screen width will change, or drift patterns
in vertical lines may be apparent.
This function enables you to adjust it and optimize
the picture.
1 From the PC Settings menu, press  or  to
select Sampling Clock.
2 Press  or  to optimize the picture.
Resetting the PC Settings
The Reset function adjusts the PC Settings to the
factory settings.
1 From the PC Settings menu, press  or  to
select Reset.
2 Press OK.
3 A con rmation message will appear. Press  or
 to select Ye s , and then press OK.
NOTE:
When a PC is connected using HDMI none of these
function will be available.
Using the Easy remote control to operate the
TV
The following TV operations can be performed
using the Easy remote control:
• When the MENU button is pressed, the menu
screen appears.
• The volume can be adjusted using the +/–
buttons.
• If you press, hold, and then tilt the pointing key
while watching the TV, the operation guide is
displayed.
Pressing, holding, and then tilting the pointing
key vertically changes the channel.
Pressing, holding, and then tilting the pointing
key horizontally changes the input.
3950L4300SeriesEn.indd313950L4300SeriesEn.indd31 2013/10/0915:23:592013/10/0915:23:59
