Security lock slot A security cable can be attached to this slot and
then connected to a desk or other large object in
order to deter theft of the computer.
Back
The following figure shows the back of computer.
Figure 3-4 The back of the computer
1. Battery pack
Battery pack The rechargeable lithium-ion battery pack
provides power to the computer when the AC
adaptor is not connected.
For more detailed information on the use and
operation of the battery pack please refer to the
Battery section.
Underside
The following figures show the underside of the computer. You should
ensure that the display is closed before the computer is turned over to
avoid causing any damage.
Figure 3-5 The underside of the computer
1. Battery lock
3. Cooling vents
2. Battery release latch 4. Memory module slot
Product appearance depends on the model you purchased.
User's Manual
3-5
