Toshiba E-studio5540c Service Manual

e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE and TROUBLESHOOTING
8 - 76
8.3.7 RADF jam
[E712] Jam not reaching the original registration sensor
[E714] Feed signal reception jam
Replace parts Remarks
Bridge unit connecting detection
switch
LGC board
Classification Error item
RADF jam The original fed from the original feeding tray does not reach
the original registration sensor.
Check item Measures
Original registration sensor • Sensor check
(Perform the input check: 03-[FAX]ON/[7]/[H])
• Connector check
• Harness check
Original pickup solenoid • Motor check
(Perform the output check: 03-)
• Connector check
• Harness check
RADF board • Connector check (CN74,CN79)
• Board check
Drive unit, Rollers • Gear check
• Roller check
Replace parts Remarks
Original registration sensor
Original pickup solenoid
RADF board Perform the 05-3210
Roller Pickup roller, feed roller, separation roller
Classification Error item
RADF jam The feed signal is received even no original exists on the
original feeding tray.
Check item Measures
Original empty sensor • Sensor check
(Perform the input check: 03-[FAX]ON/[7]/[B])
• Connector check
• Harness check
RADF board • Connector check (CN74)
• Board check
Drive unit, Rollers • Gear check
• Roller check
