Toshiba E-studio5540c Service Manual

e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE and TROUBLESHOOTING
8 - 82
[E860] Original jam access cover open jam
Intermediate transport sensor • Sensor check
(Perform the input check: 03: [FAX]/ON/[8]/[G])
• Connector check
• Harness check
Reading end sensor • Sensor check
(Perform the input check: 03: [FAX]/ON/[7]/[F])
• Connector check
• Harness check
Exit sensor • Sensor check
(Perform the input check: 03: [FAX]/ON/[7]/[E])
• Connector check
• Harness check
RADF board • Connector check (CN74, CN75)
• Board check
Drive unit, Rollers • Gear check
• Roller check
Replace parts Remarks
Original exit reverse sensor
Registration sensor
Original width detection sensor-1
Original width detection sensor-2
Original width detection sensor-3
Intermediate transport sensor
Reading end sensor
Exit sensor
RADF board Perform the 05-3210
Roller
Classification Error item
RADF jam The Original jam access cover has opened during RADF
operation.
Check item Measures
Original jam access cover • Close the Original jam access cover if it is opened.
• Remove if there is any original before closing it.
Original jam access cover opening/
closing sensor
• Sensor check
(Perform the input check: 03: [FAX]/ON/[7]/[C])
• Connector check
• Harness check
RADF board • Connector check (CN74)
• Board check
Replace parts Remarks
Original exit reverse sensor
RADF board Perform the 05-3210
Check item Measures
