8
© 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C
ERROR CODE and TROUBLESHOOTING
8 - 89
[EA25] Paper transport jam in Finisher (after paper stack was exited)
[EA26] Paper transport jam in Finisher (Stop signal received from equipment)
[EA27] Paper transport jam in Finisher (Paper not inserted but paper detected)
Replace parts Remarks
Entrance sensor (S1)
Transport sensor (S2)
Entrance motor (M1)
Finisher controller board
Classification Error item
Finisher jam
(Finisher section)
[MJ-1103/1104]
Check item Measures
Finisher • Check if there is any paper in the finisher or on the
transport path of the equipment and remove it if there is.
Finishing tray paper detection sensor
(S12)
• Sensor check
• Connector check
• Harness check
Finisher controller board • Connector check(CN18)
• Board check
Replace parts Remarks
Finishing tray paper detection sensor
(S12)
Finisher controller board
Classification Error item
Finisher jam
(Finisher section)
[MJ-1103/1104]
Check item Measures
Finisher • Check if there is any paper in the finisher or on the
transport path of the equipment and remove it if there is.
Entrance sensor (S1) • Sensor check
• Connector check
• Harness check
Finisher controller board • Connector check(CN26)
• Board check
Replace parts Remarks
Entrance sensor (S1)
Finisher controller board
To Next Page
