Power indicator The Power indicator normally glows white when
the computer is turned on. However, if you turn
the computer off into Sleep Mode, this indicator
will flash amber.
HDD/SSD/Optical Disc
Drive indicator
The HDD/SSD/Optical Disc Drive indicator
blinks white whenever the computer is accessing
the built-in HDD/SSD/Optical Disc Drive.
Wireless
communication
indicator
The Wireless communication indicator glows
white when the Wireless functions are turned on.
Some models are equipped with Wireless
functions.
Wireless WAN/WiMAX
indicator
The Wireless WAN/WiMAX indicator glows
blue when the Wireless WAN/WiMAX functions
are turned on.
In some models, the indicator will glow and blink
in order to indicate the connection status of the
Wireless WAN/WiMAX function.
Some models are equipped with a Wireless
WAN/WiMAX function.
Left side
The following figure shows the left side of the computer.
Figure 3-2 The left side of the computer
1. DC IN 19V jack
4. Universal Serial Bus (USB 3.0) port
2. Cooling vents 5. Universal Serial Bus (USB 3.0) port
3. External RGB monitor port 6. HDMI out port
Product appearance depends on the model you purchased.
User's Manual
3-2
