4 Replacement Procedures 4.11 Fingerprint Scanner Bracket
Satellite A660/A665/A660D Maintenance Manual 4-34
Installing the Fingerprint Scanner Bracket
Install the fingerprint scanner bracket according to the following procedures.
1. Turn the logic upper assembly upside down.
2. Use your fingers to press and hold down the wings on either side of the fingerprint
scanner bracket as shown in Figure 4.22.
3. Place the bottom edge of the fingerprint scanner bracket in the proper position.
4. Lower the top edge of the fingerprint scanner bracket and press down until it snaps into
place.
