Chapter 4 Replacement Procedures
4.13 CPU Heat Sink
Removing the CPU heat sink
The following describes the procedure for removing the CPU heat sink (See Figure 4-13-1).
1. Disconnect the Heat sink cable from the connector on the mother board
2. Remove the following screws securing the heat sink holder along 1 to 3.
ï‚· M2.0ï‚´2.5 screw x3
NOTE: When removing the heat sink holder, be sure to remove the screws in the reverse
order of the number marked on the holder.
Figure 4-13-1 Remove the CPU heat sink
Satellite L640/L645, Satellite Pro L640/Pro L645 Maintenance Manual (960-Q08)
