Toshiba Satellite L640 User Manual

Chapter 4 Replacement Procedures
Satellite L640/L645, Satellite Pro L640/Pro L645 Maintenance Manual (960-Q08)
51
Installing the LCD unit
The following describes the procedure for installing the LCD unit.
Install the LCD supports (LCD unit side) and hinge to the LCD and secure them with the
following screws.
 M2.03.0 BINK screw x4
1. Stand the LCD unit on the display cover and connect the LCD harness to the
connector on the back of LCD.
2. Stick the kapton tape on the connector of LCD harness.
3. Secure the LCD unit with the following screws.
 M2.5x5.0 screw x4
4. Secure the display mask with following screws
 M2. 55.0 screw x4
5. Cover screws with Screw Mylar cover
NOTE: When installing the display mask, make sure there is no gap between the display
mask and the display cover.

Toshiba Satellite L640 Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	802.11b/g/n
Webcam	Integrated Webcam
Processor	Intel Core i3/i5
RAM	Up to 8GB DDR3
Storage	320GB HDD
Display	14-inch HD
Graphics	Intel HD Graphics
Operating System	Windows 7 Home Premium
LAN	10/100 Ethernet
Battery	6-cell Lithium Ion
Ports	HDMI, VGA, RJ-45, Microphone input, Headphone output
