3. How to set the environments for connecting OPC
24
<7> Click <OK> on “My Computer Properties”
dialog.
Figure 3.3 Changing default properties (Windows 8.1/ Windows 7/Windows Vista/
Windows Server 2008/Windows Server 2008 R2/Windows Server 2012 R2)
OPC Server Setting
This Setting is on PC for OPC Server.
<1> Execute the commands in the
following order: “Console Root”
→ “Component Services” →
“Computers” → “My Computer.
Select “DCOM Config” and
select “TOSHIBA TC-net OPC
Data Access Server” in the
application list.
Right-click the “TOSHIBA
TC-net OPC Data Access
Server” and select “Property”
menu.
To Next Page
