Mouse
Printer
To connect a Serial Device, follow the steps as detailed below:
1. Turn the computer’s power off.
2. Remove the cap of the Serial port conversion cable.
3. Connect the Serial port conversion cable to your computer.
Figure 4-27 Connecting the Serial Connector
1. Serial Connector 2. Serial port conversion cable
Security lock
A security lock enables you to anchor your computer to a desk or other
heavy object in order to help prevent unauthorized removal or theft. The
computer has a security lock slot into which you can attach one end of the
security cable, while the other end attaches to a desk or similar object. The
methods used for attaching security cables differ from product to product.
Please refer to the instructions for the product you are using for more
information.
Connecting the security lock
In order to connect a security cable to the computer, follow the steps as
detailed below:
1. Turn the computer so the security lock slot faces you.
2. Align the security cable with the lock slot and secure it in place.
Figure 4-28 Security lock
1. Security lock slot
2. Security lock
User's Manual 4-53
