59
Installation and Maintenance
Service Manual
The data above are subject to change without notice.
NO.
Description
Part Code
QtyTM18HEDI
Product Code CV010N01100_L81561
1 Front Panel Assy 20012756_L81561 1
2 Filter Sub-Assy 11122119 1
3 Front Case Assy 20012601 1
4 Evaporator Assy 01002608 1
5 Temp Sensor Sleeving 05212423 1
6 Rear Case assy 22202462 1
7 Centrifugal Fan 10312005 1
8 Fan Motor 1570410001201 1
9 Step Motor 1521210805 1
10 Crank 73012005 1
11 Swing Assy 10102042 1
12 Terminal Board 422000000022 1
13 Switch Board 30112007 1
14 Display Board 30568131 1
15 Fuse 46010055 1
16 Radiator 49010252 1
17 Signal Wire 4003004202 1
18 Jumper 4202300103 1
19 Main Board 30138613 1
20 Electric Box 20112116 1
21 Electric Box Assy 2020242301 1
22 Air Louver (upper) 10512143 2
23 Swing Lever 10582096 2
24 Shaft of Guide Louver 10542020 2
25 Rear Grill 01472024 1
26 Water Tray Assy 20182141 1
27 Air Louver (lower) 10512144 2
28 Axis (lower step motor) 10542034 1
29 Step Motor 1521210101 1
30 Tube Sensor 390000591 1
31 Remote Controller 30510135_TOSOT 1
32 Pipe Connection Nut Accessories 06320020 1
33 Ambient Temperature Sensor 390000453 1
