Tosot TM09HEDI User Manual

2
Technical Information
Service Manual
2.Specications
2.1 Specication Sheet
Model
Console
TM09HEDI TM12HEDI TM18HEDI
Product Code CV010N00900_L81561 CV010N01000_L81561 CV010N01100_L81561
Rated Voltage V~ 208-230 208-230 208-230
Rated Frequency Hz 60 60 60
Phases 1 1 1
Cooling Capacity W 2640 3520 5280
Heating Capacity W 2780 3810 5800
Air Flow Volume (H/M/L)
m
3
/h 560/480/370 650/550/450 800/650/530
Dehumidifying Volume L/h 0.8 1.4 1.8
Fan Type Centrifugal Centrifugal Centrifugal
Fan Diameter-height mm Φ370X80 Φ370X80 Φ370X80
Fan Motor Speed (SH/H/M/L)(Cool) rpm 650/560/530/480/430/370/320 750/650/600/550/500/450/350 840/800/720/650/580/530/410
Fan Motor Speed (SH/H/M/L)(Heat) rpm 650/560/530/480/430/370/320 750/650/600/550/500/450/350 900/840/760/690/620/570/450
Fan Motor Power Output W 30 30 30
Fan motor running current A 0.14 0.14 0.14
Evaporator Material Aluminum Fin-copper Tube Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7 Φ7 Φ7
Evaporator Number of Rows
2 2 2
Evaporator Fin Pitch mm 1.3 1.3 1.3
Evaporator Length(L) X Height(H)
X Width(W)
mm 511X396X24 511X396X24 511X396X24
Motor Model FN30F-ZL FN30F-ZL FN30F-ZL
Overload Protector 3.15 3.15 3.15
Motor Full Load Amp(FLA) A 0.14 0.14 0.14
Sound Pressure Level (H/M/L) dB(A) 38/33/26 40/37/32 46/41/35
Sound Power Level (H/M/L)
dB(A) 48/43/36 50/47/33 56/51/45
Outline Dimension (WXHXD) mm 700X600X215 700X600X215 700X600X215
Package Carton Dimension
(LXWXH)
mm 785X280X682 785X280X682 785X280X682
Package Dimension (LXWXH) mm 788X283X697 788X283X697 788X283X697
Net Weight kg 15 15 15
Gross Weight kg 18 18 18
Liquid pipe mm Φ6 Φ6 Φ6
Gas Pipe(to indoor unit) mm Φ9.52 Φ9.52 Φ12
The above data is subject to change without notice. Please refer to the nameplate of the unit.
