3
Technical Information
Service Manual
Model
Cassette
TM12HKDI
TM18HKDI
TM24HKDI
Product Code CN51000060_L8156 CN51000070_L8156 CN51000080_L8156
Cooling Capacity kW 3.5 4.5 6.682
Btu/h 12000 14400 22800
Heating Capacity kW 4 5 8.03
Btu/h 13000 16000 27400
Air ow volume(H) m
3
/h 600 600 1180
CFM
353 353 694
Sound Pressure Level (H) dB(A) 46 46 39
Sound Power Level (H) dB(A) 56 56 49
Rated Voltage V 208/230 208/230 208/230
Rated Frequency Hz 60
60 60
Phases 1
1 1
Fan Type Axial-ow Centrifugal Axial-ow
Motor Full Load Amp(FLA) A 0.18 0.18 0.43
Fan Motor Speed rpm 845/700/600/515 845/700/600/515 620/570/520/280
Fan Motor Power Output W 11 11 50
Fan Motor Power Input
W 50 50 100
Fan motor running current A 0.23 0.23 0.43
Fan Motor Capacitor μF 1 1 3
Gas Pipe(to indoor unit) mm Φ9.52 Φ12
Φ16
Liquid pipe mm Φ6.35 Φ6 Φ9.52
Connection method Flare Connection Flare Connection Flare Connection
Drain Connection (outer diameter) mm 31 31 31
Dimension of Outline (WXDXH) mm 570X570X230 570X570X230 840X840X240
Dimension of Carton Box (LXWXH) mm 848X728X310 848X728X310 960X960X310
Dimension of Package (LXWXH) mm 851X731X325 851X731X325 963X963X325
Net/Gross Weight kg 18.0/23.0 18.0/23.0 30.0/38.0
The above data is subject to change without notice. Please refer to the nameplate of the unit.
