Technical Information
Service Manual
Model
Duct Type
TM18HFDI TM24HFDI TM09HFDI
Product Code
CN210N0080_L81561 CN210N0100_L81561 CN210N0070_L81561
Cooling Capacity kW
4.484 6.975 2.491
Btu/h
15300 23800 8500
Heating Capacity kW
5.481 8.03 2.784
Btu/h
18700 27400 9500
Air ow volume(H) m
3
/h
700 1000 450
CFM
412 589 265
Sound Pressure Level (H) dB(A)
41/37/33 42/38/34 37/34/31
Sound Power Level (H) dB(A)
50/47/43 52/48/44 47/44/41
Rated Voltage V
208/230 208/230 208/230
Rated Frequency Hz
60 60 60
Phases
1 1 1
Fan Type
Centrifugal Centrifugal Centrifugal
Motor Full Load Amp(FLA) A
0.41 0.5 0.28
Fan Motor Speed rpm
1000/920/780/720 1160/985/800/680 1230/970/760/640
Fan Motor Power Output W
75 22.5 40
Fan Motor Power Input
W
100 124 80
Fan motor running current A
0.43 0.54 0.35
Fan Motor Capacitor μF
3 3 1.5
Gas Pipe(to indoor unit) mm
Φ12.7 Φ15.9 Φ9.52
Liquid pipe mm
Φ6 Φ9.52 Φ6
Connection method
Flare Connection Flare Connection Flare Connection
Drain Connection (outer diameter) mm
26 26 26
Drain Connection (outer diameter) inch
1 1 1
Dimension of Outline (WXDXH) mm
900X615X200 1100X615X200 700X615X200
Dimension of Carton Box (LXWXH) mm
1123X743X305 1323X743X305 893X743X305
Dimension of Package (LXWXH) mm
1126X746X320 1326X746X320 896X746X320
Net/Gross Weight kg
36/27 41/31 27/22
The above data is subject to change without notice. Please refer to the nameplate of the unit.
