Tosot TM09HEDI User Manual

5
Technical Information
Service Manual
Model
Floor Ceiling Type
TM24HTDI TM18HTDI TM12HTDI
Product Code
CN610N0080_L81561 CN610N0050_L81561 CN610N0070_L81561
Cooling Capacity kW
6.68 5 3.5
Btu/h
22800 17000 11900
Heating Capacity kW
8.03 5.5 3.85
Btu/h
27400 18700 13100
Air ow volume(H) m
3
/h
1250 950 650
CFM
736 559 383
Sound Pressure Level (H) dB(A)
48/46/44 45/42/40 40/38/36
Sound Power Level (H) dB(A)
58/56/50 55/52/50 50/48/46
Rated Voltage V
208/230 208/230 208/230
Rated Frequency Hz
60 60 60
Phases
1 1 1
Fan Type
Centrifugal Centrifugal Centrifugal
Motor Full Load Amp(FLA) A
0.5 0.5 0.3
Fan Motor Speed rpm
1160±30/985±30/800±35/680±35 1160±30/985±30/800±35/680±35 790±30/690±30/610±40/480±40
Fan Motor Power Output W
40 20 15
Fan Motor Power Input
W
145 110 55
Fan motor running current A
0.63 0.56 0.28
Fan Motor Capacitor μF
3 2.5 1
Gas Pipe(to indoor unit) mm
Φ16 Φ12 Φ9.52
Liquid pipe
mm
Φ9.52 Φ6 Φ6
Connection method
Flare Connection Flare Connection Flare Connection
Drain Connection (outer diameter) mm
17 17 17
Dimension of Outline (WXDXH) mm
1220X700X225 1220X700X225 1220X700X225
Dimension of Carton Box (LXWXH) mm
1340X820X300 1340X820X300 1340X820X300
Dimension of Package (LXWXH) mm
1343X823X315 1343X823X315 1343X823X315
Net/Gross Weight kg
45.0/54.0 40.0/50.0 40.0/50.0
The above data is subject to change without notice. Please refer to the nameplate of the unit.
