Tosot TM09HEDI User Manual

6
Technical Information
Service Manual
Model
Duct Type
TM12HFDI TM09HTDI
Product Code
CN210N0060_L81561 CN610N0060_L81561
Cooling Capacity kW
3.488 2.50
Btu/h
11900 8500
Heating Capacity kW
3.839 2.80
Btu/h
13100 9500
Air ow volume(H) m
3
/h
500 650/550/450
CFM
294 383/324/265
Sound Pressure Level (H) dB(A)
39/35/32 40/38/36
Sound Power Level (H) dB(A)
49/45/42 50/48/46
Rated Voltage V
208/230 208/230
Rated Frequency Hz
60 60
Phases
1 1
Fan Type
Centrifugal Centrifugal
Motor Full Load Amp(FLA) A
0.3 0.3
Fan Motor Speed rpm
1130/960/830/700 690/610/480
Fan Motor Power Output W
49 15
Fan Motor Power Input
W
80 55
Fan motor running current A
0.35 0.28
Fan Motor Capacitor μF
3 1
Gas Pipe(to indoor unit) mm
Φ9.52 Φ9.52
Liquid pipe
mm
Φ6 Φ6
Connection method
Flare Connection Flare Connection
Drain Connection (outer diameter)
mm
26 17
Dimension of Outline (WXDXH) mm
700X615X200 1220X700X225
Dimension of Carton Box (LXWXH) mm
893X743X305 1340X820X300
Dimension of Package (LXWXH) mm
896X746X320 1343X823X315
Net/Gross Weight kg
23/29 40/50
The above data is subject to change without notice. Please refer to the nameplate of the unit.
