65
Installation and Maintenance
Service Manual
The data above are subject to change without notice.
NO.
Description
Part Code
QtyTM09HFDI TM12HFDI
Product Code CN210N0070_L81561 CN210N0060_L81561
1 Air outlet frame assy 01865216 01865216 1
2 Cover of air outlet 01265298 01265298 1
3 Water Tray Assy 01285332 01285332 1
4 Top Cover Board Assy 01265325 01265325 1
5 Evaporator Assy 01024266 01024905 1
6 Plate of the Evaporator Sub-Assy 01495317 01495317 1
7 Left Side Plate Assy 01315334 01315334 1
8 Plate of the Exit Tube Sub-Assy 01495316 01495316 1
9 Front volute casing 26905205 26905205 2
10 Rear volute casing 26905206 26905206 2
11 Centrifugal fan 10425200 10425200 2
12 Transformer 43110233 43110233 1
13 Terminal Board 420001000002 420001000002 1
14 Main Board 30226339 30226338 1
15 Capacitor 3301074701 3301074704 1
16 Electric Box Sub-Assy 01395100 01395100 1
17 Electric Box assy 01395980 01395983 1
18 Electric Box Cover 01424253 01424253 1
19 Cover Plate of the Fan 01265300 01265300 1
20 Bottom Cover Plate 01265299 01265299 1
21 Supporter 01895225 01895225 1
22 Bar Clasp 70818405 70818405 1
23 Fan Motor 150101000076 1570520106 1
24 Supporter 01805288 01805288 1
25 Fan Mounting Plate Assy 01325312 0132531201 1
26 Right Side Plate Assy 01315335 01315335 1
27 Display Board 30296317 30296317 1
28 Ambient Temperature Sensor 39000206 39000206 1
29 Temperature Sensor 390001982G 390001982G 1
30 Water Pump Assy 15405241 15405241 1
31 Water Level Switch 45010201 45010201 1
32 Water Pump 43130324 43130324 1
33 Remote Controller 305100492 305100492 1
To Next Page
