67
Installation and Maintenance
Service Manual
The data above are subject to change without notice.
NO.
Description
Part Code
QtyTM18HFDI
Product Code CN210N0080_L81561
1 Air outlet frame assy 1865217 1
2 Cover of air outlet 1265331 1
3 Water Tray Assy 1285333 1
4 Evaporator Assy 1024268 1
5 Lower Cover Plate Sub-Assy 1265328 1
6 Left Side Plate Assy 1315334 1
7 Plate of the Evaporator Sub-Assy 1495317 1
8 Plate of the Exit Tube Sub-Assy 1495316 1
9 Front volute casing 26905205 3
10 Rear volute casing 26905206 3
11 Bottom Cover Plate 80050053 1
12 Transformer 43110233 1
13 Terminal Board 420001000002 1
14 Main Board 30226338 1
15 Capacitor 3301074704 1
16 Electric Box Sub-Assy 1395100 1
17 Electric Box assy 1395984 1
18 Electric Box Cover 1424253 1
19 Temperature Sensor 39000206 1
20 Ambient Temperature Sensor 39000206 1
21 Cover Plate of the Fan 1265333 1
22 Fan Motor 150101000070 1
23 Bar Clasp 70818405 1
24 Supporter 1805288 1
25 Joint Slack 73018731 1
26 Supporter 1895225 1
27 Rotary Axis Sub-Assy 73018731 1
28 Centrifugal fan 10425200 3
29 Fan Mounting Plate Assy 1325314 1
30 Right Side Plate Assy 1305263 1
31 Display Board 30296317 1
32 Water Pump Assy 15405241 1
33 Water Level Switch 45010201 1
34 Water Pump 43130324 1
35 Remote Controller 305100492 1
To Next Page
