Installation and Maintenance

Service Manual

Steps Procedure

inhalation tube sub-

assy

oil separator sub-assy

Unsolder all spot welds oil separator sub-assy and

then remove the oil separator sub-assy.

Note:When unsoldering the spot weld, wrap the gas

valve and liquid valve with wet cloth completely to

avoid damage to valve due to high temperature.

Remove all spot welds inhalation tube sub-assy, and

then remove the inhalation tube sub-assy.

Remove all spot welds electromagnetic valve sub-

assy and then remove the electromagnetic valve sub-

assy.

11. Remove oil separator sub-assy

12. Remove

inhalation tube sub-assy

electromagnetic

valve sub-assy

13. Remove electromagnetic valve sub-assy
