Total 74-00 - Operating Instructions; Technical Data

MAINTENANCE INSTRUCTIONS
HALON 1 / 1,2 / 2,5 AIR TOTAL
ATA 26-24-05 I 74/76-00 dated May 2014
Page 5 of 13
Subject to change without notice Replaces H 74/76-00 dated October 2012
*
*
*
*
Release: Operating instructions: August 2003
Technical data: January 2005
Operating instructions
When held in place with a strap, open fastener and remove extinguisher from bracket. Bent
down safety lever (black), remove seal wire and than squeeze release lever (red). Attack fire with
the discharging extinguishing agent.
Attack the fire starting from front. Discharge agent in shots according to requirements.
Technical data
Part. No.
Dimensions
Height Dia.
Weight w/o
bracket and
fastening strap
Kg Lbs
Weight bracket
and fastening
strap approx.
Kg Lbs
Nominal
pressure
by 15C/
59F
Container
test
press.
Filling
Kg Lbs
Discharge
time
approx.
Heights
74-00
265mm
10.4 in.
82mm
3.2in.
1.99
4.39
0.21
0.46
11 bar
156.5 psi
30 bar
427 psi
1
2.2
7 sec
20.000m
65.616 ft.
74-20
265mm
10.4 in.
82mm
3.2in.
2.19
4.83
0.21
0.46
11 bar
156.5 psi
30 bar
427 psi
1.2
2.65
9 sec
20.000m
65.616 ft.
74-21
265mm
10.4 in.
82mm
3.2in.
2.19
4.83
0.5
1.10
11 bar
156.5 psi
30 bar
427 psi
1.2
2.65
9 sec
20.000m
65.616 ft.
76-00
380mm
15 in.
100mm
4in.
4.02
8.86
0.41
0.90
11 bar
156.5 psi
30 bar
427 psi
2.5
5.51
10 sec
20.000m
65.616 ft.
* for exact weight see the check note label on the extinguishers backside.
(1) Operating temperature range
All fire extinguishers can be operated at temperatures of between -40°C and +70°C
(-40°F and +158°F).
(2) Throw distance
Throw distance for the extinguishers 74-00, 74-20, 74-21 and 76-00 is 3.50 m
(11.5 Ft) at +20°C (+68°F).
