Total TP880-1 - Vibrator Component Details; Major Components of Vibrator Assembly

No. Exploding view QTY
52-1 Flange bolt 8
52-2 Crank case cover 1
52-3 Paper gasket 1
52-4 Clip 1
52-5 Big gear 1
52-6 Deep groove ball bearing 1
52-7 Clip 1
52-8 Deep groove ball bearing 1
52-9 Clip 1
52-10 Crank Case 1
52-11 Nylon closed cover 1
52-12 Connecting rod 1
52-13 Deep groove ball bearing 2
52-14 clip 1
52-15 Small gear 1
52-16 key 1
52-17 Deep groove ball bearing 1
52-18 Oil seal 1
52-19 Clutch support drum 1
52-20 Quenched Flat washer 1
52-21 Spr
ing washer 1
52-22 External hexagon bolt 1
TP880-1,TP880-2,TP880-3
Major components of vibrator assy
30
