ALWAYS unplug this fireplace heater before assembly or cleaning, or before
relocating. Failure to do so could result in electric shock, fire, or personal injury.
STEP 2. A. Locate the wall studs using an electronic stud-finder. Mark the hole locations with a
pencil. The holes should be 8” (20.3 cm) apart, and level. The minimum height from the surface
below must be 6” (30 cm). B. Three screws should be screwed directly into wall studs. Then, four
drywall anchors are needed.
AVOID INJURY and DAMAGE! Three screws should be screwed directly into wall
studs. and additional screws must also be screwed into the drywall anchors.
Due to the many different materials used on different walls, it is highly recommended
that you consult your local builder before you install this appliance on the wall.
A.Select a location that is not prone to moisture and is located at least 36" (914mm)
away from combustible materials such as curtain drapes, furniture, bedding, paper, etc.
B.Have two people hold the appliance against the wall to determine the final location.
C.Place unit face down on a soft, non abrasive surface. Remove the bracket from the
back of the unit by removing the screws, refer to Figure 1.
D.Mark out location, then mount the bracket(s) onto the wall using the supplied screws.
This bracket MUST have the hooks facing upward and be level.
NOTE: It is strongly recommended that the mounting bracket be Screwed into
Where possible. If the wall
Studs cannot be used, ensure
That the supplied plastic anchors are used to affix the bracket to the wall and the
bracket is adequately secured.
E. With the wall mounting bracket installed have two people lift the appliance up and
