Touchstone 80024 - RECESSED TO WALL INSTALLATION

7
RECESSED TO WALL INSTALLATION
(A)
(B)
STEP A. Selection a dry wall to open a hole for fireplace box. Size of hole as below chart
Figure ( A )
Model Number
W
H
80024
43.9”
19”
STEP B. Fix the three wall anchors in each side of the fireplace box according to the
dimensions showed on the drawing. Figure (B)
