TouchWo TD55HD - Technical Parameters; System Design; LED Parameters

TD55HD Touchwo Touch screen All in one /Monitor
2
 Simple Installation：wall mounted/desktop stand/embedded etc installations, plug and play. No need to debug;
 Strict quality control: the monitors have undergone multiple tests such as 48-hour ageing, electrostatic testing,
vibration, voltage/electronic load test, voltage withstand test, touch/calibration test, controlled high
temperature test, constant temperature and humidity test, controlled drop test.
2Technical Parameters
2.1
System Design
Output（AIO pc）
Inside HDMI/VGA output
Input （touch monitor）
VGA、HDMI,DVI input
Touch function
Latest projected capacitive touchscreen, 10 fingers touch
Display
HDMI/VGA support 1080P
PC
1080P （Full HD）MPEG、H.264.,etc
Structure design
Backlit integrated structure, reasonable heat dissipation
System modules
Combined PC,display,touch all-in-one
2.2 LED Panel Parameters
Panel type
LED panel (a-Si TFT-LCD WLED backlight), A grade
Size
55 inch(16:9)
Display area
1212（W）*683.7（H）mm
Max. resolution
Default is 1920*1080P (optional 3840*2160P )
Brightness
≥300cd/m2
Contrast
≥1200：1
Response time
6(Typ.)(Tr/Td) ms
Refresh
60Hz
No. of colors
16.7M（LVDS, 51 Pins）
Angle of viewing
Full viewing89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Life time
30000H
