FEATURES DIAGRAM
1 Door latch - If the door is opened while the oven is
operating, cooking will automatically stop.
2 Door seal - The door seal surfaces prevent microwaves
escaping from the oven cavity.
3 Oven cavity
4 Control panel
5 Door open button - To open the door push the door
open button.
6 Coupler- This fits over the shaft in the centre of the
oven cavity floor.
This is to remain in the oven for all cooking.
7 Roller guide - This must always be used for cooking
together with the glass cooking tray.
8 Glass cooking tray - Made of special heat resistant
glass. The tray must always be in proper position before
operating. Do not cook food directly on the tray.
9 Viewing screen - Allows viewing of food.
The screen is designed so that light can pass through,
but not microwaves.
0 Waveguide cover - Protects the microwave outlet from
spattering food.
q Safety interlock system
w Variable Power Control Knob - Used to select a
microwave power level.
e Timer knob - Used in setting cooking time for all
functions.
r Oven lamp - Automatically turns on when the oven is
operating.
