Before First Use:
Read all instructions and safety information carefully before first use. Please retain this information
for future reference.
1. Remove the parts from the packaging and lay out on an even surface.
2. Assemble as per the assembly instructions using a flat head screwdriver.
3. Wash the grill plate, grease pan and cover thoroughly. The grill plate and the grease pan are
both dishwasher safe.
IMPORTANT: Dry all the different parts thoroughly. This applies especially to the appliance socket
Never immerse the temperature controller in water.
4. Your appliance is now ready for normal use.
5. Dispose of the packaging in a responsible manner.
Assembly:
Install the plastic pad (14)
Take a straight tube (11) one of the feet pads
(14). Align the position of the notch (1a) of the
straight tube (11) with the stopper (1b) of the
foot (14) to prevent it from turning
Then tighten with the screw ‘A’ from the
bottom of the foot (14)
Install the other three sets in this same way.
(Note: There are two straight tubes (11) with
shrink tubes (1c) at the other end, and the
other two straight tubes (11) with no shrink
tubes (1c), they should be placed separately).
Place the two plastic rack holders (13) on a
flat surface (The inner sides (2a) face to face).
Take a U-shaped tube (10) and position with
the screw holes “2c”, “2d”, and “2e” facing
outward. Insert into holes (2b) of two brackets.
Then insert another U-shaped tube (10) into
the bracket holes on the other side.
(Hint: Take the U-shaped tube (10) and make
sure the side with the screw holes is facing
outward.)
Set up two U-shaped tubes (10) and turn over.
Make sure that the screw holes (2c) at the
bottom of the U-shaped tubes (10) from the
mouth of the tubes expose the gap in the
plastic bracket (13) to facilitate subsequent
installation and screws position.
