9
Insert the grease pan (5) into the holder on
the back of the base (6).
To securely secure the grease pan, align the
hole in the grease pan with the positioning
protrusion located in the centre of the base.
The grease pan can be removed and washed.
Make sure that the grease pan is replaced
after cleaning.
Note: The capacity of the grease pan is 0.3
litres. Pour out the fat as soon as the pan is
full. The surface of the grease pan becomes
very hot. Use heat-resistant gloves if you have
to remove the pan.
Place the grill plate (4) on the base of
appliance (6).
Insert the appliance socket (20) on the
backside of the grill plate (4) into the opening
intended for it (17), then set the grill plate
horizontally on the appliance base.
Align the handle (2) with the two mounting
holes on the cover (3) and tighten with screw
(F)
Insert the thermometer (1) into the hole of the
cover (3) and tighten with screw nut (N) from
the cover inside.
