8
Place the semicircular groove (7a) at one end
of the centre base (8) on the arc surface (7b)
corresponding of the U-shaped tube (10).
Align the two screw holes (2e).
Then take a Butterfly screw (C) and insert it
into the washer (D) to align and tighten the
two screw holes (2e).
Place the rack (12) on the corresponding
plane inside the plastic rack holder (13).
The full frame is assembled.
Make sure the side with the word ‘FRONT’ on
the frame centre base (8) is facing you, Match
the hole of the bowl-shaped base (6) and
locate the stand tube (7) in the centre base
hole (8)
7
