2004 CELICA (EWD538U)
111
P1 BACK-UP LIGHT SW [PARK/NEUTRAL POSITION SW] (A/T)
3-2 : Closed with the shift lever at R position
B1 BACK-UP LIGHT SW (M/T)
2-1 : Closed with the shift lever in R position
: PARTS LOCATION
Code See Page Code See Page Code See Page
32 (1ZZ-FE) J12 A 38 P1 A 35 (2ZZ-GE)
B1 B
34 (2ZZ-GE) J13 B 38 R6 39
C12 36 P1 A 33 (1ZZ-FE) R7 39
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
IB 25 Engine Room Main Wire and Instrument Panel J/B (Instrument Panel Brace RH)
2C 23 Engine Wire and Engine Room J/B (Engine Compartment Left)
2F 23 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IE4 44 Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Brace LH)
II2 46 Engine Room Main Wire and Floor Wire (Instrument Panel Brace LH)
: GROUND POINTS
Code See Page Ground Points Location
IH 44 Cowl Side Panel RH
BL 48 Back Panel Center
SERVICE HINTS
