2004 CELICA (EWD538U)
210
COMBINATION METER
B2 BRAKE FLUID LEVEL WARNING SW
1-2 : Closed with the float down
P3 PARKING BRAKE SW
1-GROUND : Closed with the parking brake lever pulled up
O2 OIL PRESSURE SW
1-GROUND : Opened with the oil pressure above approx. 0.2 kgf/cm
2
(2.8 psi, 19.6 kpa)
C12 (A) COMBINATION METER
(A)22-GROUND : Approx. 12 volts with the ignition SW at ON position
(A)11-GROUND : Always approx. 12 volts
(A)3, (A) 7, (A) 10, (A) 19-GROUND : Always continuity
: PARTS LOCATION
Code See Page Code See Page Code See Page
32 (1ZZ-FE) D4 38 J8 37
B2
34 (2ZZ-GE) E2 A 32 (1ZZ-FE)
33 (1ZZ-FE)
B6 A 36 E3 B 32 (1ZZ-FE)
O2
35 (2ZZ-GE)
B7 B 36 E5 D 32 (1ZZ-FE) O3 37
B8 36 E7 34 (2ZZ-GE) P3 37
B9 36 E8 E 34 (2ZZ-GE)
33 (1ZZ-FE)
C12 A 36 F12 36
V1
35 (2ZZ-GE)
C13 B 36 F17 38
D3 38 J5 37
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
IB 25 Engine Room Main Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IF
II
25 Instrument Panel Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IM
2C 23 Engine Wire and Engine Room J/B (Engine Compartment Left)
2D
Engine Room Main Wire and Engine Room J/B (Engine Com
2F
23 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
Engine Wire and Engine Room Main Wire (Inside of Engine Room R/B No 1)
EA2
42 (2ZZ-GE)
Engine Wire and Engine Room Main Wire (Inside of Engine Room R/B No.1)
IE3
IE4
44 Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Brace LH)
IE5
II2 46 Engine Room Main Wire and Floor Wire (Instrument Panel Brace LH)
: GROUND POINTS
Code See Page Ground Points Location
EB
42 (2ZZ-GE)
Front Left Fender
IF 44 Instrument Panel Brace RH
IH 44 Cowl Side Panel RH
SERVICE HINTS
To Next Page
