’04 Solara_U (L/O 0402)
317
2004 SOLARA from Feb. ’04 Prod. (OM33640U)
NOTICE
! Be sure the engine and all accesso-
ries are off before performing main-
tenance.
! When checking the battery, remove
the ground cable from the negative
terminal (“−” mark) first and rein-
stall it last.
! Be careful not to cause a short cir-
cuit with tools.
! Take care no solution gets into the
battery when washing it.
If the battery is disconnected or run
down, the driver’s power window and
moon roof may not operate automatically
and the jam protection function will not
function correctly after you reconnect, re-
place or recharge the battery. In any of
these cases, you should normalize the
power window and moon roof. To normal-
ize the power window and moon roof, see
“Power windows” on page 23 and “Electric
moon roof” on page 33 in Section 1−2.
Type A
Green Dark
Clear or
light yellow
Type B
Blue White Red
CHECKING BY INDICATOR
Check the battery condition by the indi-
cator color.
Indicator color
Condition
Type A Type B
Green Blue Good
Dark White
Charging necessary.
Have battery
checked by your
Toyota dealer.
Clear or
light
yellow
Red
Have battery
checked by your
Toyota dealer.
During recharging, the battery is pro-
ducing hydrogen gas.
Therefore, before recharging:
1. If recharging with the battery installed
on the vehicle, be sure to disconnect
the ground cable.
2. Be sure the power switch on the re-
charger is off when connecting the
charger cables to the battery and when
disconnecting them.
CAUTION
! Always charge the battery in an un-
confined area. Do not charge the
battery in a garage or closed room
where there is not sufficient ventila-
tion.
! Only do a slow charge (5 A or
less). Charging at a quicker rate is
dangerous. The battery may ex-
plode, causing personal injuries.
NOTICE
Never recharge the battery while the
engine is running. Also, be sure all
accessories are turned off.
—Checking battery condition Battery recharging precautions
To Next Page
