4-3. Do-it-yourself maintenance

■ Tail and back-up lights

Remove the back door trim

board.

Turn the bulb base counterclock-

wise.

Tail l ight

Back-up light

Remove the light bulb.

Tail l ight

Back-up light

STEP

1

STEP

2

STEP

3
