Toyota 4RUNNER 2012 - Page 533

560
4-3. Do-it-yourself maintenance
4RUNNER_U
15 H-LP RH-HI
10 A
Right-hand headlight (high
beam)
16 H-LP LH-HI
10 A
Left-hand headlight (high
beam)
17 HTR
50 A
Air conditioning system
18 400W INV
80 A
Power outlets
19 ST
30 A
Starter system
20 H-LP HI
20 A
H-LP RH-HI, H-LP LH-HI fuses
21 ALT-S
7.5 A
Charging system
22 TURN&HAZ
15 A
Turn signal lights, emergency
flashers
23 ETCS
10 A
Multiport fuel injection system/
sequential multiport fuel injec-
tion system
24 PRB
30 A
Automatic running boards sys-
tem
25 TOWING
30 A
Trailer stop/turn lights
26 SHORT PIN
⎯
No circuit
27 RAD NO.1
10 A
Audio system
28 AM2
7.5 A
Starter system
29 MAYDAY
7.5 A
MAYDAY
30 AMP
30 A
Audio system
31 ABS NO.1
50 A
ABS, VSC
32 ABS NO.2
30 A
ABS, VSC
33 DOME
10 A
Interior lights, vanity lights
34 ECU-B
10 A
Multiplex communication sys-
tem, meter and gauge
35 H-LP RH-LO
10 A
Right-hand headlight (low
beam)
36 H-LP LH-LO
10 A
Left-hand headlight (low beam)
37 INJ
10 A
Multiport fuel injection system/
sequential multiport fuel injec-
tion system
38 EFI NO.2
7.5 A
Multiport fuel injection system/
sequential multiport fuel injec-
tion system
Fuse Ampere Circuit
